压舱的主要目的是保持船舶的稳定性,在调节倾斜和吃水差的同时在港口为货物操作提供便利,以优化船舶的性能和降低燃料成本.
训练和熟悉船上压载系统,管路设置,压载水处理系统和相关设备
确保有效管理压舱水,包括定期检查安装的压舱水报警和鸣声设备,这将有助于防止沉积物或碎片的积累,这些沉积物或碎片可能是入侵物种.
压载水相关操作要求船上船员应做到如下:
·评估用作压载的水的适宜性和质量。如果可能,可通过内部转移已经载入船上的压载水来实现所需的压载。
·确定在货物操作和航行的不同阶段所需的压载水数量,制定压舱水计划,规定所需的压舱物数量和需要充填和排空的舱位的顺序。同时考虑到任 泵的限制,并规划以安全的速度进行压舱。
考虑压载舱所产生的自由表面效应
在装货操作前获得装卸顺序。如果提供的顺序计划引起任何稳定性或船体应力问题,这些问题无法通过使用压舱水来实现时,应立即提请码头注意进行纠正.
确保所有压载水舱液位测量计正常工作并提供可靠的读数。对于手动测量,以合适的测量间隔和报告。如果在极地区操作,应确保测量管和压载水舱液位计不会受到极端寒冷天气的影响
根据需要维护和更新压载水管理记录
考虑到附近的船只。对于加油过程中排水不会造成损坏或影响其安全。
在浅水区进行压载时要小心,因为这会导致压载泵过滤器堵塞,沉淀物沉积在水箱内。
另外对于压载水负责人的专业要求记录以及考虑以上各点针对性培训尤为重要.
国际海事组织海洋环境保护委员会在2024年9月30日至10月4日举行的第82次MEPC 会议上批准通过了BWM.2/Circ 80/Rev. 1。该通函生效后,要求从2025年2月1日起按照统一的记录格式和表格进行压载水记录,为在压载水记录簿中记录与挑战性的水质相关的运营情景提供明确指导。
海保会第80次会议批准了《压载水记录保存和报告指南》(BWM.2/Circ.80),以澄清何时以及如何记录BWRB中的操作。该指南包括三个部分:
1. 压载水记录簿:包括标准化格式,以方便高效的记录保存和检查,以及记录存储说明。指南附录一中的示例条目说明了如何在压载水记录簿中记录各种压载水操作和情况。
2. 压载水报告表格:包含一份压载水报告表格(BWRF)的示例,以及填写说明。BWRF可在进入要求提供有关船舶压载水管理的具体信息的港口国之前提交,这些船舶的目的港、公海或锚地位于该港口国境内。
3. 自愿逐仓记录:说明如何保持自愿逐仓记录压载水操作,这可以方便完成BWRF,使船员能够有效地跟踪载有压载水的每个 舱室的内容
现分享一下2025年2月1日后,推荐的压载水记录簿的代码以及记录格式如下:
代码A
指压载压入作业,也就是当压载水从海里打入压载舱时,需要记录6项内容:
1. 起始时间和位置(吸入港口或经纬度)
2. 完成时间和地点(吸入港口或纬度/经度和采集时最小水深)
3. 受影响的压载水舱
4. 估计泵入量及最终留存总量(以立方米计)
5. 是否按照批准的压载水管理计划进行
6. 压载水处理方法
(A) When ballast water is taken on board from the aquatic environment (ballasting operation)
.1 Start time and location (port of uptake or latitude/longitude)
.2 Completion time and location (port of uptake or latitude/longitude and minimum depth of water during uptake)
.3 The identity of the tanks affected
.4 Estimated volume of uptake and final total quantity retained in cubic metres
.5 Whether conducted in accordance with the approved Ballast Water Management Plan
.6 Ballast water treatment method
记录分在港记录与海上记录,2个记录推荐格式如下:
1.一艘需要达到D-1标准的船舶,如果在不按照BWMP处理的情况下装载压舱水,则必须在第5项中记录“yes.Ballasting done as per the BWMP for D-1 compliance”(按照BWMP进行D-1合规的压舱水作业),在第6项中记录“None”(无)。当船舶后来进行压舱水交换时,必须在代码C下记录。
2.例子1和2考虑新的进水量为6800立方米,而现有处理过的水量为400立方米。将处理过的水与未处理的水混合将导致满负荷被认为无法管理。
3.如果船舶必须吸入未经管理的压载水,第5项必须写上“否”,第6项必须写“否”,并说明理由。
当压舱水被装载到船上(压舱操作)时——在港口(或海)根据批准的压载水管理计划,在船上使用压载舱或航程中处理
1.BWMS采用“压载舱”处理压载水直接压入压载舱没有任何处理。在吸收点,进入必须按照上例.ltem 6例必须说明“无。根据BWMS”
2.随后,在使用代码C2进行压载舱内或循环时,船舶必须按照C例。
代码B
指压载水排出作业,也就是当压载水从舱内排出到海里,需要记录6项内容:
1. 开始排放时间和地点(排放港或经纬度)
2. 完成排放的时间和地点(排放港或经纬度和排放时 最小水深)
3. 受影响的压载舱
4. 估计排水量及最终剩余量(以立方米计)
5. 是否按照批准的压载水管理计划进行
6. 压载水处理方法
Code B
(B) When ballast water is discharged into the aquatic environment (deballasting operation)
.1 Start time and location (port of discharge or latitude/longitude)
.2 Completion time and location (port of discharge or latitude/longitude and minimum depth of water during discharge)
.3 The identity of the tanks affected
.4 Estimated volume of discharge and final total quantity retained in cubic metres
.5 Whether conducted in accordance with the approved Ballast Water Management Plan
.6 Ballast water treatment method
当按照《压载水管理计划》管理的压载水被排放入在港内时
当按照《压载水管理计划》管理的压载水被排放入海时
1. 对于D-1认证的船舶,第5项应输入为“YES。D-1合规”,第6项应输入为“No”。
2. 使用单程处理系统(仅用于压入)且在卸货期间不进行处理的船舶,应在第6项中记录“None,根据BWMS设计”。
3.根据批准的BWMP的应急计划管理的船舶排空水,记录如下:
当压舱水未按《压载水管理计划》管理后排放到海洋时
代码C
指压载水置换作业,这里分2种情况:一是压载水置换作业,二是压载水通过内部循环处理或在压载舱中处理作业。2种处理方式记录不一样,尤其需要关注。
1. 压载水置换作业
1.1 开始时间和地点
1.2 完成时间和地点
1.3 置换时距离最近陆地的最小距离和最小水深,或根据规则B-4.2指定的交换区域(如适用)
1.4 是否按照压载水管理计划进行,还需描述使用的压载水置换方法
1.5 受影响的压载舱
1.6 置换量和最终剩余量(以立方米计)
1.7 泵入压载水的处理方法
Code C
(C) Whenever ballast water is exchanged, or treated in-tank or treated through internal circulation
1 Ballast water exchange
.1 Start time and location (latitude/longitude)
.2 Completion time and location (latitude/longitude)
.3 Minimum distance from the nearest land and minimum depth of water during the exchange or, if applicable, identify the designated exchange area in accordance with regulation B-4.2
.4 Whether conducted in accordance with the Ballast Water Management Plan and state the ballast water exchange method (sequential or flow-through or dilution) used
.5 The identity of the tanks affected
.6 Total quantity exchanged and final total quantity on board in cubic metres
.7 Treatment method for the incoming ballast water
2.压载水内部循环处理或舱内处理
2.1 开始时间
2.2 完成时间
2.3 受影响液舱的标识(如适用,标识出来源舱和目的舱)
2.4 (通过循环或舱内)处理的总量(立方米)
2.5 压载水处理方法
(C) 2 Ballast water internal circulation for treatment or in-tank treatment
.1 Start time
.2 Completion time
.3 The identity of the tanks affected (identifying source and destination tanks if applicable)
.4 Total quantity treated (through circulation or in tank) in cubic metres
.5 Ballast water treatment method
压载水置换没有压载水处理装置
压载水置换有批准的压载水处理装置
压舱水内部循环处理或舱内处理
代码D
指从港口或接收设施压入或排放压载水,需要记录7项内容:
1. 开始压入/排放的时间和地点
2. 完成时间
3. 进行的操作(压入或排出)
4. 受影响的压载舱
5. 排放或压入量和船上的剩余量(以立方米计)
6. 是否按照批准的压载水管理计划进行
7. 船舶压载水处理方法
Code D
(D) Uptake or discharge of ballast water from/to a port-based or reception facility
.1 Start time and location of uptake/discharge (state facility name)
.2 Completion time
.3 Operation carried out (whether uptake or discharge)
.4 The identity of the tanks affected
.5 Total quantity in cubic metres and final quantity retained on board
.6 Whether conducted in accordance with the approved Ballast Water Management Plan
.7 Onboard ballast water treatment method
压载水从码头压入时,记录推荐
压载水排向码头或接收设施时,记录推荐
代码E
指压载水的意外排放/泵入或其他异常泵入或排放,需要记录6项内容:
1. 浸入/泵入/排出的起始时间和位置
2. 完成时间
3. 采取的操作(浸入、泵入或排出)
4. 受影响的压载舱
5. 压载水总量(以立方米计)
6. 说明浸入、泵入、排放或损失的情况及其原因,以及所使用的任何处理方法和一般备注
Code E
(E) Accidental discharge/ingress or other exceptional uptake or discharge of ballast water
.1 Start time and location of ingress/uptake/discharge (port name or latitude/longitude)
.2 Completion time
.3 Operation carried out (whether ingress, uptake or discharge)
.4 The identity of the tanks affected
.5 Total quantity of ballast water in cubic metres
.6 State the circumstances of ingress, uptake, discharge or loss, the reason thereof, any treatment method used and general r
事故性进水,记录
由于事故排水
特殊情况
代码F
指压载水管理系统故障或不可操作,需要记录4 项内容:
1. 压载水管理系统发生故障的时间和位置
2. 已进行的操作(说明是否吸收或排放)
3. 问题描述(如报警类型)
4. 时间和位置(港口名称或经纬度)
Code F
(F) Failures and inoperabilities of the ballast water management system
.1 Time and location (port name or latitude/longitude) of failure of the ballast water management system
.2 Operation carried out (state whether uptake or discharge)
.3 Description of the issue (e.g. kind of alarm or other description of circumstances)
.4 Time and location (port name or latitude/longitude) when the ballast water management system has been made operational
设备故障,立即修复
设备故障,不能修复
代码G
指压载舱清洗/冲洗、清除和处置沉淀物,需要记录5项内容:
1. 压载舱开始清洗/冲洗、清除或处置沉积物的时间和船舶位置
2. 完成压载舱清洗/冲洗、清除或处置沉积物的时间和船舶位置
3. 压载舱名称(根据压载水管理计划的压载舱名称)
4. 排放或处置至接收设施的数量以及设施名称
5. 根据压载水管理计划处置或排放到水生环境(数量以立方米计,距最近陆地以海里计,最小水深以米计)
6. 压载水处理方法
Code G
(G) Ballast tank cleaning/flushing, removal and disposal of sediments
.1 Time and ship's location on commencement of ballast tank cleaning/flushing, removal or disposal of sediments (port name or latitude/longitude)
.2 Time and ship's location on completion of ballast tank cleaning/flushing, removal or disposal of sediments (port name or latitude/longitude)
.3 Tank(s) identification (name of the ballast tanks as per the Ballast Water Management Plan)
.4 Discharge or disposal to a reception facility (state quantity in cubic metres and name of the facility)
.5 Disposal or discharge to the aquatic environment as per Ballast Water Management Plan (state quantity in cubic metres, minimum distance from the nearest land in nm and minimum depth of water in metres)
压载水舱的清洗和沉积物的排放到接收设施/干坞
压舱水清洗/冲洗和沉积物处置(在海上)
代码H
指其他操作程序和一般说明。
Code H
(H) Additional operational procedures and general remarks
压载舱内转载压载水
压水取样
压载水舱用于非压载水用途:停止使用
参阅文件:
MEPC.369(80)
Amendments to the International Convention for the Control and Management of Ships’ Ballast Water and Sediments, 2004. Amendments to appendix II (Form of Ballast Water Record Book)
BWM.2/Circ.80/Rev.1
2024 Guidance on ballast water record-keeping and reporting
MEPC.387(81)
Interim guidance on the application of the BWM Convention to ships operating in challenging water quality conditions
MEPC.127(53)
Guidelines for ballast water management and development of Ballast Water Management Plans (G4)
MEPC.306(73)
Amendments to the Guidelines for ballast water management and development of Ballast Water Management Plans (G4) (resolution MEPC.127(53))
MEPC.370(80)
Amendments to the Guidelines for ballast water management and development of Ballast Water Management Plans (G4) (resolution MEPC.127(53), as amended by resolution MEPC.306(73))
MEPC.372(80)
Guidelines for the use of electronic record books under the BWM Convention
MEPC.383(81)
Amendments to the International Convention for the Control and Management of Ships’ Ballast Water and Sediments, 2004. Amendments to regulations A-1 and B-2 (Use of electronic record books)
BWM-2-Circ-80-Rev-1.pdf
MEPC.127(53).pdf
MEPC.306(73).pdf
MEPC.370(80).pdf
MEPC.372(80).pdf
MEPC.387(81).pdf
MEPC-369-80.pdf
MEPC-383-81.pdf
